Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ATCA-07-151M-HFIXED IND 150UH 4A 53 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 150 µH | ±20% | 4 A | - | Unshielded | 53mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" Dia (36.00mm) | 0.768" (19.50mm) |
|
ATCA-07-300M-VFIXED IND 30UH 10A 9 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 30 µH | ±20% | 10 A | - | Unshielded | 9mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" L x 0.768" W (36.00mm x 19.50mm) | - |
|
|
ATCA-07-680M-VFIXED IND 68UH 7A 21 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 68 µH | ±20% | 7 A | - | Unshielded | 21mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" L x 0.768" W (36.00mm x 19.50mm) | - |
|
|
ATCA-07-820M-VFIXED IND 82UH 7A 23 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 82 µH | ±20% | 7 A | - | Unshielded | 23mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" L x 0.768" W (36.00mm x 19.50mm) | - |
|
|
ATCA-07-151M-VFIXED IND 150UH 4A 53 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 150 µH | ±20% | 4 A | - | Unshielded | 53mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" L x 0.768" W (36.00mm x 19.50mm) | - |
|
|
ATCA-07-201M-HFIXED IND 200UH 3A 78 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 200 µH | ±20% | 3 A | - | Unshielded | 78mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" Dia (36.00mm) | 0.768" (19.50mm) |
|
|
ATCA-07-201M-VFIXED IND 200UH 3A 78 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 200 µH | ±20% | 3 A | - | Unshielded | 78mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" L x 0.768" W (36.00mm x 19.50mm) | - |
|
ASPIAIG-Q1060-4R7M-TFIXED IND 4.7UH 14A 10.72MOHM SM Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1060 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 4.7 µH | ±20% | 14 A | 22A | Shielded | 10.72mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.469" L x 0.433" W (11.90mm x 11.00mm) | 0.236" (6.00mm) |
|
|
ASPIAIG-Q1060-3R3M-TFIXED IND 3.3UH 16.8A 7.7MOHM SM Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1060 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 3.3 µH | ±20% | 16.8 A | 25A | Shielded | 7.7mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.469" L x 0.433" W (11.90mm x 11.00mm) | 0.236" (6.00mm) |
|
|
ATCA-07-350M-HFIXED IND 35UH 10A 10 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 35 µH | ±20% | 10 A | - | Unshielded | 10mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" Dia (36.00mm) | 0.768" (19.50mm) |
