Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ATCA-05-182M-VFIXED IND 1.8MH 1A 680 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Vertical (Open) | Tray | Active | Toroidal | Iron Powder | 1.8 mH | ±20% | 1 A | - | Unshielded | 680mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.181" L x 0.669" W (30.00mm x 17.00mm) | - |
|
ASPIAIG-Q1513-6R8M-TFIXED IND 6.8UH 27A 4.2MOHM SMD Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 6.8 µH | ±20% | 27 A | 32A | Shielded | 4.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-8R2M-TFIXED IND 8.2UH 26A 5.7MOHM SMD Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 8.2 µH | ±20% | 26 A | 29A | Shielded | 5.7mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-330M-TFIXED IND 33UH 14A 22.2MOHM SMD Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 33 µH | ±20% | 14 A | 16A | Shielded | 22.2mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-220M-TFIXED IND 22UH 17A 13.86MOHM SMD Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 22 µH | ±20% | 17 A | 19A | Shielded | 13.86mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-5R6M-TFIXED IND 5.6UH 29A 3.9MOHM SMD Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 5.6 µH | ±20% | 29 A | 35A | Shielded | 3.9mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
|
ASPIAIG-Q1513-150M-TFIXED IND 15UH 22A 7.5 MOHM SMD Abracon LLC |
0 |
|
Таблицы данных |
ASPIAIG-Q1513 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 15 µH | ±20% | 22 A | 21A | Shielded | 7.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.689" L x 0.650" W (17.50mm x 16.50mm) | 0.512" (13.00mm) |
|
ATCA-07-300M-HFIXED IND 30UH 10A 9 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 30 µH | ±20% | 10 A | - | Unshielded | 9mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" Dia (36.00mm) | 0.768" (19.50mm) |
|
|
ATCA-07-680M-HFIXED IND 68UH 7A 21 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 68 µH | ±20% | 7 A | - | Unshielded | 21mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" Dia (36.00mm) | 0.768" (19.50mm) |
|
|
ATCA-07-820M-HFIXED IND 82UH 7A 23 MOHM TH Abracon LLC |
0 |
|
Таблицы данных |
ATCA | Radial, Horizontal (Open) | Tray | Active | Toroidal | Iron Powder | 82 µH | ±20% | 7 A | - | Unshielded | 23mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Through Hole | - | 1.417" Dia (36.00mm) | 0.768" (19.50mm) |
