Автомобильные реле
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Упаковка | Состояние продукта | Тип катушки | Ток катушки | Напряжение катушки | Форма контакта | Номинал контакта (ток) | Напряжение переключения | Необходимое рабочее напряжение | Необходимое отпускающее напряжение | Время срабатывания | Время отпускания | Особенности | Тип крепления | Тип вывода | Рабочая температура |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2-1904025-5V23234A0004X053-EV-100 |
0 |
|
Таблицы данных |
Power Relay B | Bulk | Obsolete | Non Latching | 94 mA | 24VDC | SPDT (1 Form C) | 50 A | 24VDC - Nom | 16 VDC | 3 VDC | 10 ms | 10 ms | Resistor | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
|
5-1393303-0RELAY GEN PURPOSE SPST 20A 24V |
0 |
|
Таблицы данных |
F4 | Bulk | Active | Non Latching | 74.1 mA | 24VDC | SPST-NO (1 Form A) | 20 A | 28VDC - Nom | 14.4 VDC | 3.2 VDC | 7 ms | 2 ms | - | Chassis Mount | Plug In, Quick Connect - 0.110" (2.8mm) | -40°C ~ 125°C |
|
CM1A-D-24VCM RELAY 1 FORM A 24V |
0 |
|
Таблицы данных |
CM | Bulk | Active | Non Latching | 75 mA | 24VDC | SPST-NO (1 Form A) | 15 A | 28VDC - Nom | 14 VDC | 2.4 VDC | 10 ms | 15 ms | Diode, Sealed - Fully | Socketable | Plug In | -40°C ~ 85°C |
|
|
4-1393303-7RELAY GEN PURPOSE SPST 40A 12V |
0 |
|
Таблицы данных |
F4 | Bulk | Active | Non Latching | 133.3 mA | 12VDC | SPST-NO (1 Form A) | 40 A | 14VDC - Nom | 7.2 VDC | 1.6 VDC | 7 ms | 2 ms | - | Chassis Mount | Plug In, Quick Connect - 0.110" (2.8mm) | -40°C ~ 125°C |
|
|
1-1393302-6RELAY AUTOMOTIVE SPST 70A 12V |
0 |
|
Таблицы данных |
VF7 | Tray | Active | Non Latching | 166 mA | 12VDC | SPST-NO (1 Form A) | 70 A | 12VDC - Nom | 7.2 VDC | 1.2 VDC | - | - | - | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | - |
|
|
02040716ZRELAY AUTOMOTIVE SPDT 40A 12V |
0 |
|
- |
ISO MINI® | Bulk | Obsolete | Non Latching | - | 12VDC | SPDT (1 Form C) | 40 A | 12VDC - Nom | - | - | - | - | Diode | Socketable | Plug In | - |
|
|
5-1393304-6V23134M0052C642 |
0 |
|
Таблицы данных |
V23134, AXICOM | Box | Active | Non Latching | 133.3 mA | 12VDC | SPST-NO (1 Form A) | 40 A | 12VDC - Nom | 7.2 VDC | 1.6 VDC | 7 ms | 2 ms | - | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
|
6-1393304-7RELAY GEN PURPOSE DPST 15A 24V |
0 |
|
Таблицы данных |
F4 | Box | Active | Non Latching | 74.1 mA | 24VDC | DPST-NO (2 Form A) | 15 A | 28VDC - Nom | 14.4 VDC | 3.2 VDC | 7 ms | 2 ms | - | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
|
3-1393303-8RELAY GEN PURPOSE SPST 20A 24V |
0 |
|
Таблицы данных |
F4 | Bulk | Active | Non Latching | 74.1 mA | 24VDC | SPST-NO (1 Form A) | 20 A | 28VDC - Nom | 14.4 VDC | 3.2 VDC | 7 ms | 2 ms | Resistor | Chassis Mount | Plug In, Quick Connect - 0.110" (2.8mm) | -40°C ~ 125°C |
|
|
02040603ZRELAY AUTOMOTIVE SPDT 20A 12V |
0 |
|
- |
MICRO | Bulk | Obsolete | Non Latching | - | 12VDC | SPDT (1 Form C) | 20 A | 12VDC - Nom | - | - | - | - | - | Socketable | Plug In | - |
|
|
02040601ZRELAY AUTOMOTIVE SPST 25A 12V |
0 |
|
- |
MICRO | Bulk | Obsolete | Non Latching | - | 12VDC | SPST-NO (1 Form A) | 25 A | 12VDC - Nom | - | - | - | - | - | Socketable | Plug In | - |
|
|
4-1904049-7V23134A0007X942-EV-590 |
0 |
|
Таблицы данных |
V23134, AXICOM | Bulk | Active | Non Latching | - | - | - | - | 12VDC - Nom | - | - | 7 ms | 2 ms | - | - | - | -40°C ~ 125°C |
|
|
1904056-2V23134A0007X936-EV-441 |
0 |
|
- |
V23134, AXICOM | Bulk | Active | Non Latching | - | - | - | - | 12VDC - Nom | - | - | 7 ms | 2 ms | - | - | - | -40°C ~ 125°C |
|
|
3-1904131-0RELAY V23134-B4052-X546 |
0 |
|
Таблицы данных |
V23134, AXICOM | Bulk | Active | Non Latching | - | 12VDC | - | - | 12VDC - Nom | - | - | 7 ms | 2 ms | - | - | - | -40°C ~ 125°C |
|
|
5-1393304-8POWER F V23134 |
0 |
|
- |
V23134, AXICOM | Bulk | Active | Non Latching | 133.3 mA | 12VDC | DPST-NO (2 Form A) | 25 A | 14VDC - Nom | 7.2 VDC | 1.6 VDC | 7 ms | 2 ms | - | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
|
8-1904049-6V23134A0007X933-EV-850 |
0 |
|
Таблицы данных |
V23134, AXICOM | Bulk | Active | Non Latching | - | - | - | - | 12VDC - Nom | - | - | 7 ms | 2 ms | - | - | - | -40°C ~ 125°C |
|
V23134-A3052-X540RELAY GEN PURPOSE SPDT 40A 12V |
0 |
|
Таблицы данных |
VF4 | Bulk | Active | Non Latching | 133 mA | 12VDC | SPDT (1 Form C) | 40 A | 14VDC - Nom | 7.2 VDC | 1.2 VDC | 7 ms | 2 ms | Resistor | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
|
1904002-2RELAY AUTO SPST-NO 50A 24V |
0 |
|
Таблицы данных |
HCR 75 | Bulk | Obsolete | Non Latching | - | 24VDC | SPST-NO (1 Form A) | 50 A | 24VDC - Nom | 19 VDC | 1 VDC | - | - | - | Chassis Mount | Screw Terminal, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
|
1904001-4RELAY AUTO SPST-NO 30A 24V |
0 |
|
Таблицы данных |
HCR 75 | Bulk | Obsolete | Non Latching | - | 24VDC | SPST-NO (1 Form A) | 30 A | 24VDC - Nom | 19 VDC | 1 VDC | 7 ms | 2 ms | - | Chassis Mount | Screw Terminal | -40°C ~ 125°C |
|
1904001-2RELAY AUTO SPST-NO 75A 12V |
0 |
|
- |
HCR 75 | Bulk | Obsolete | Non Latching | - | 12VDC | SPST-NO (1 Form A) | 75 A | 12VDC - Nom | 8 VDC | 4 VDC | 10 ms | 15 ms | - | Chassis Mount | Screw Terminal | -40°C ~ 100°C |
