Тантало-полимерные конденсаторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Емкость | Допуск | Напряжение - Номинальное | Тип | ESR (эквивалентное последовательное сопротивление) | Рабочая температура | Срок службы при темп. | Тип крепления | Размер/измерение | Высота - в сидячем положении (макс.) | Расстояние между выводами | Код размера производителя | Номинальные значения | Особенности |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TCH9336M075W0120CCAP TANT POLY 33UF 75V SMD KYOCERA AVX |
7 |
|
- |
TCH | Nonstandard | Bulk | Active | 33 µF | ±20% | 75 V | Hermetically Sealed | 120mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 85°C | Surface Mount | 0.472" L x 0.492" W (12.00mm x 12.50mm) | 0.333" (8.45mm) | - | - | COTS | High Reliability |
|
|
TCH9226M100W0150CCAP TANT POLY 22UF 100V SMD KYOCERA AVX |
10 |
|
- |
TCH | Nonstandard | Bulk | Active | 22 µF | ±20% | 100 V | Hermetically Sealed | 150mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 85°C | Surface Mount | 0.472" L x 0.492" W (12.00mm x 12.50mm) | 0.333" (8.45mm) | - | - | COTS | High Reliability |
|
TCJA156M010R0200ECAP TANT POLY 15UF 10V 1206 KYOCERA AVX |
35 |
|
- |
TCJ | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 15 µF | ±20% | 10 V | Molded | 200mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.071" (1.80mm) | - | A | - | General Purpose |
|
|
TCJA107M004R0200ECAP TANT POLY 100UF 4V 1206 KYOCERA AVX |
131 |
|
- |
TCJ | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 100 µF | ±20% | 4 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.071" (1.80mm) | - | A | - | General Purpose |
|
|
TCJB226M020R0150CAP TANT POLY 22UF 20V 1210 KYOCERA AVX |
70 |
|
- |
TCJ | 1210 (3528 Metric) | Tape & Reel (TR) | Active | 22 µF | ±20% | 20 V | Molded | 150mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
|
|
TCJD337M004R0040CAP TANT POLY 330UF 4V 2917 KYOCERA AVX |
65 |
|
- |
TCJ | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 330 µF | ±20% | 4 V | Molded | 40mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | - | General Purpose |
|
|
TCJY107M010R0018CAP TANT POLY 100UF 10V 2917 KYOCERA AVX |
1,000 |
|
- |
TCJ | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 100 µF | ±20% | 10 V | Molded | 18mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.079" (2.00mm) | - | Y | - | General Purpose |
|
|
TCJC685M035R0200CAP TANT POLY 6.8UF 35V 2312 KYOCERA AVX |
83 |
|
- |
TCJ | 2312 (6032 Metric) | Tape & Reel (TR) | Active | 6.8 µF | ±20% | 35 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.236" L x 0.126" W (6.00mm x 3.20mm) | 0.110" (2.80mm) | - | C | - | General Purpose |
.jpg)
|
TCQD337M006R0025CAP TANT POLY 330UF 6.3V 2917 KYOCERA AVX |
66 |
|
- |
TCQ | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 330 µF | ±20% | 6.3 V | Molded | 25mOhm @ 100kHz | -55°C ~ 125°C | 1000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | AEC-Q200 | Automotive |
|
|
TCJC685M050R0200ECAP TANT POLY 6.8UF 50V 2312 KYOCERA AVX |
60 |
|
- |
TCJ | 2312 (6032 Metric) | Tape & Reel (TR) | Active | 6.8 µF | ±20% | 50 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.236" L x 0.126" W (6.00mm x 3.20mm) | 0.110" (2.80mm) | - | C | - | General Purpose |
