БОМ
Триак, выходные оптоизоляторы SCR
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип выхода | Цепь пересечения нуля | Количество каналов | Напряжение - Изоляция | Напряжение - Выкл. | Статическое dV/dt (мин.) | Ток - светодиодный триггер (Ift) (макс.) | Ток - Вкл. состояние (It (RMS)) (макс.) | Ток - Удержание (Ih) | Время включения | Напряжение - прямое (Vf) (тип.) | Ток - постоянный ток вперед (If) (макс.) | Рабочая температура | Тип крепления | Устройство поставщика Упаковка | Сертифицирующее агентство |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EL3061-VOPTOISOLATOR 5KV TRIAC 6DIP |
0 |
|
Таблицы данных |
- | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | Yes | 1 | 5000Vrms | 600 V | 1kV/µs | 15mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Through Hole | 6-DIP | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE |
.JPG)
|
EL3062S1(TB)OPTOISOLATOR 5KV TRIAC 6SMD |
0 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 5000Vrms | 600 V | 1kV/µs | 10mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Surface Mount | 6-SMD | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL |
|
|
EL3062S1(TB)-VOPTOISOLATOR 5KV TRIAC 6SMD |
0 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 5000Vrms | 600 V | 1kV/µs | 10mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Surface Mount | 6-SMD | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE |
|
EL3063MOPTOISOLATOR 5KV TRIAC 6DIP |
0 |
|
Таблицы данных |
- | 6-DIP (0.400", 10.16mm) | Tube | Active | Triac | Yes | 1 | 5000Vrms | 600 V | 1kV/µs | 5mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Through Hole | 6-DIP | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL |
|
|
EL3063S1(TB)OPTOISOLATOR 5KV TRIAC 6SMD |
0 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 5000Vrms | 600 V | 1kV/µs | 5mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Surface Mount | 6-SMD | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL |
|
|
EL3063S1(TB)-VOPTOISOLATOR 5KV TRIAC 6SMD |
0 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 5000Vrms | 600 V | 1kV/µs | 5mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Surface Mount | 6-SMD | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE |
|
|
EL3082S(TB)OPTOISOLATOR 5KV TRIAC 6SMD |
0 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 5000Vrms | 800 V | 600V/µs | 10mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Surface Mount | 6-SMD | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL |
|
|
EL3083-VOPTOISOLATOR 5KV TRIAC 6DIP |
0 |
|
Таблицы данных |
- | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | Yes | 1 | 5000Vrms | 800 V | 600V/µs | 5mA | 100 mA | 280µA (Typ) | - | 1.5V (Max) | 60 mA | -55°C ~ 100°C | Through Hole | 6-DIP | CSA, DEMKO, FIMKO, NEMKO, SEMKO, UL, VDE |
|
MOC3052S-TAOPTOISOLATOR 5KV TRIAC 6SMD |
0 |
|
Таблицы данных |
MOC305x | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | No | 1 | 5000Vrms | 600 V | 1kV/µs | 10mA | - | 400µA (Typ) | - | 1.2V | 50 mA | -40°C ~ 100°C | Surface Mount | 6-SMD | CSA, FIMKO, UL |
|
VO3526OPTOISOLTR 5.3KV PWR TRIAC 10DIP |
0 |
|
Таблицы данных |
- | 16-DIP (0.300", 7.62mm), 10 Leads | Tube | Obsolete | Triac, Power | No | 1 | 5300Vrms | 600 V | 210V/µs (Typ) | 10mA | 1 A | 25mA | - | 1.4V (Max) | 50 mA | -40°C ~ 85°C | Through Hole | 10-DIP | cUR, UR, VDE |
|
IL4216-X006OPTOISOLATOR 5.3KV TRIAC 6DIP |
0 |
|
Таблицы данных |
- | 6-DIP (0.400", 10.16mm) | Tube | Obsolete | Triac | No | 1 | 5300Vrms | 600 V | 10kV/µs | 700µA (Typ) | 300 mA | 200µA | - | 1.3V | 60 mA | -55°C ~ 100°C | Through Hole | 6-DIP | BSI, CSA, cUR, FIMKO, UR |
|
IL4217-X009OPTOISOLATOR 5.3KV TRIAC |
0 |
|
Таблицы данных |
- | 6-SMD | Tube | Obsolete | Triac | No | 1 | 5300Vrms | 700 V | 10kV/µs | 700µA (Typ) | 300 mA | 200µA | - | 1.3V | 60 mA | -55°C ~ 100°C | Surface Mount | - | BSI, CSA, cUR, FIMKO, UR |
|
|
K3010P-X007TOPTOISOLATOR 5.3KV TRIAC 6SMD |
0 |
|
- |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | Triac | No | 1 | 5300Vrms | 250 V | 10kV/µs (Typ) | 15mA | 100 mA | 100µA (Typ) | - | 1.25V | 80 mA | -55°C ~ 100°C | Surface Mount | 6-SMD | BSI, CQC, UR, VDE |
|
|
K3010PGOPTOISOLATOR 5.3KV TRIAC 6DIP |
0 |
|
- |
- | 6-DIP (0.400", 10.16mm) | Tube | Obsolete | Triac | No | 1 | 5300Vrms | 250 V | 10kV/µs (Typ) | 15mA | 100 mA | 100µA (Typ) | - | 1.25V | 80 mA | -55°C ~ 100°C | Through Hole | 6-DIP | BSI, CQC, UR, VDE |
|
|
K3012P-X007TOPTOISOLATOR 5.3KV TRIAC 6SMD |
0 |
|
- |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | Triac | No | 1 | 5300Vrms | 250 V | 10kV/µs (Typ) | 5mA | 100 mA | 100µA (Typ) | - | 1.25V | 80 mA | -55°C ~ 100°C | Surface Mount | 6-SMD | BSI, CQC, UR, VDE |
|
|
IL420-X008TOPTOISOLATOR 5.3KV TRIAC |
0 |
|
Таблицы данных |
- | 6-SMD | Tape & Reel (TR) | Obsolete | Triac | No | 1 | 5300Vrms | 600 V | 10kV/µs | 2mA | 300 mA | 500µA | 35µs | 1.16V | 60 mA | -55°C ~ 100°C | Surface Mount | - | CQC, CSA, cUR, UR |
|
|
IL4108-X001OPTOISOLATOR 5.3KV TRIAC SMD |
0 |
|
Таблицы данных |
- | 6-SMD, Gull Wing | Tube | Obsolete | Triac | Yes | 1 | 5300Vrms | 800 V | 10kV/µs | 2mA | 300 mA | 500µA | 35µs | 1.16V | 60 mA | -55°C ~ 100°C | Surface Mount | SMD | CSA, UR, VDE |
|
|
IL4108-X006OPTOISOLATOR 5.3KV TRIAC 6DIP |
0 |
|
Таблицы данных |
- | 6-DIP (0.400", 10.16mm) | Tube | Obsolete | Triac | Yes | 1 | 5300Vrms | 800 V | 10kV/µs | 2mA | 300 mA | 500µA | 35µs | 1.16V | 60 mA | -55°C ~ 100°C | Through Hole | 6-DIP | CSA, UR |
|
|
IL4116-X019TOPTOISOLATOR 5.3KV TRIAC |
0 |
|
Таблицы данных |
- | 6-SMD | Tape & Reel (TR) | Obsolete | Triac | Yes | 1 | 5300Vrms | 600 V | 10kV/µs | 1.3mA | 300 mA | 200µA | 35µs | 1.3V | 60 mA | -55°C ~ 100°C | Surface Mount | - | BSI, CSA, cUR, FIMKO, UR, VDE |
|
|
IL4118-X016OPTOISOLATOR 5.3KV TRIAC 6DIP |
0 |
|
Таблицы данных |
- | 6-DIP (0.400", 10.16mm) | Tube | Obsolete | Triac | Yes | 1 | 5300Vrms | 800 V | 10kV/µs | 1.3mA | 300 mA | 200µA | 35µs | 1.3V | 60 mA | -55°C ~ 100°C | Through Hole | 6-DIP | BSI, CSA, cUR, FIMKO, UR, VDE |
