Сдвиговые регистры
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип логики | Тип выхода | Количество элементов | Количество бит на элемент | Функция | Напряжение - Питание | Рабочая температура | Марка | Квалификация | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
74F299SCXPARALLEL IN PARALLEL OUT Fairchild Semiconductor |
16,122 |
|
Таблицы данных |
74F | 20-SOIC (0.295", 7.50mm Width) | Bulk | Active | Shift Register | Tri-State | 1 | 8 | Universal | 4.5V ~ 5.5V | 0°C ~ 70°C | - | - | Surface Mount | 20-SOIC |
|
74F350SCSHIFTER, F/FAST SERIES Fairchild Semiconductor |
3,194 |
|
Таблицы данных |
74F | 16-SOIC (0.154", 3.90mm Width) | Bulk | Active | - | Tri-State | 1 | 4 | - | 4.5V ~ 5.5V | 0°C ~ 70°C | - | - | Surface Mount | 16-SOIC |
|
74VHC595SJSERIAL IN PARALLEL OUT Fairchild Semiconductor |
22,936 |
|
Таблицы данных |
74VHC | 16-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | Shift Register | Tri-State | 1 | 8 | Serial to Parallel, Serial | 2V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 16-SOP |
|
DM74LS166WMXPARALLEL IN SERIAL OUT, 8-BIT Fairchild Semiconductor |
7,000 |
|
Таблицы данных |
74LS | 16-SOIC (0.295", 7.50mm Width) | Bulk | Active | Shift Register | - | 1 | 8 | Parallel or Serial to Serial | 4.75V ~ 5.25V | 0°C ~ 70°C | - | - | Surface Mount | 16-SOIC |
|
74F323PCPARALLEL IN PARALLEL OUT Fairchild Semiconductor |
1,332 |
|
Таблицы данных |
74F | 20-DIP (0.300", 7.62mm) | Tube | Obsolete | Register, Bidirectional | Tri-State | 1 | 8 | Universal | 4.5V ~ 5.5V | 0°C ~ 70°C | - | - | Through Hole | 20-PDIP |
|
74VHC595NSERIAL IN PARALLEL OUT Fairchild Semiconductor |
25,000 |
|
Таблицы данных |
74VHC | 16-DIP (0.300", 7.62mm) | Tube | Obsolete | Shift Register | Tri-State | 1 | 8 | Serial to Parallel, Serial | 2V ~ 5.5V | -40°C ~ 85°C | - | - | Through Hole | 16-PDIP |
|
74VHC164NSERIAL IN PARALLEL OUT Fairchild Semiconductor |
10,146 |
|
Таблицы данных |
74VHC | 14-DIP (0.300", 7.62mm) | Tube | Obsolete | Shift Register | Push-Pull | 1 | 8 | Serial to Parallel | 2V ~ 5.5V | -40°C ~ 85°C | - | - | Through Hole | 14-DIP |
|
74VHC164SJSERIAL IN PARALLEL OUT Fairchild Semiconductor |
9,635 |
|
Таблицы данных |
74VHC | 14-SOIC (0.209", 5.30mm Width) | Tube | Obsolete | Shift Register | Push-Pull | 1 | 8 | Serial to Parallel | 2V ~ 5.5V | -40°C ~ 85°C | - | - | Surface Mount | 14-SOP |
|
|
74F299PCPARALLEL IN PARALLEL OUT Fairchild Semiconductor |
4,391 |
|
Таблицы данных |
74F | 20-DIP (0.300", 7.62mm) | Tube | Obsolete | Shift Register | Tri-State | 1 | 8 | Universal | 4.5V ~ 5.5V | 0°C ~ 70°C | - | - | Through Hole | 20-PDIP |
|
MM74HC164NSERIAL IN PARALLEL OUT Fairchild Semiconductor |
1,837 |
|
Таблицы данных |
74HC | 14-DIP (0.300", 7.62mm) | Tube | Obsolete | Shift Register | Push-Pull | 1 | 8 | Serial to Parallel | 2V ~ 6V | -40°C ~ 85°C | - | - | Through Hole | 14-DIP |
