Буферы сигналов, повторители, разветвители
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Применение | Вход | Выход | Скорость передачи данных (макс.) | Количество каналов | Время задержки | Кондиционирование сигнала | Емкость - вход | Напряжение - Питание | Ток - Питание | Рабочая температура | Марка | Квалификация | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
89HP0608SZBABIIC REDRIVER I2C 8CH 100BGA |
0 |
|
Таблицы данных |
- | 100-LFBGA | Tray | Obsolete | Buffer, ReDriver | I2C | 2-Wire Bus | 2-Wire Bus | 6Gbps | 8 | - | - | - | - | - | - | - | - | Surface Mount | 100-CABGA (9x9) |
|
|
89HP0608SZBABI8IC REDRIVER I2C 8CH 100BGA |
0 |
|
Таблицы данных |
- | 100-LFBGA | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | I2C | 2-Wire Bus | 2-Wire Bus | 6Gbps | 8 | - | - | - | - | - | - | - | - | Surface Mount | 100-CABGA (9x9) |
|
89HP0608XZBABG8IC REDRIVER I2C 8CH 100BGA |
0 |
|
Таблицы данных |
- | 100-LFBGA | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | I2C | 2-Wire Bus | 2-Wire Bus | 6.25Gbps | 8 | - | - | - | - | - | - | - | - | Surface Mount | 100-CABGA (9x9) |
|
|
89HP0608XZBABGIIC REDRIVER I2C 8CH 100BGA |
0 |
|
Таблицы данных |
- | 100-LFBGA | Tray | Obsolete | Buffer, ReDriver | I2C | 2-Wire Bus | 2-Wire Bus | 6.25Gbps | 8 | - | - | - | - | - | - | - | - | Surface Mount | 100-CABGA (9x9) |
|
|
89HP0608XZBABGI8IC REDRIVER I2C 8CH 100BGA |
0 |
|
Таблицы данных |
- | 100-LFBGA | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | I2C | 2-Wire Bus | 2-Wire Bus | 6.25Gbps | 8 | - | - | - | - | - | - | - | - | Surface Mount | 100-CABGA (9x9) |
|
PI2EQX3201BLZFEIC REDRIVER SATA2 2CH 36TQFN |
0 |
|
Таблицы данных |
ReDriver™ | 36-WFQFN Exposed Pad | Tray | Obsolete | Buffer, ReDriver | SATA2 | CML | CML | 3Gbps | 2 | 2.0ns | Input Equalization, Output De-Emphasis | - | 1.5V, 1.8V | 90mA | -40°C ~ 85°C | - | - | Surface Mount | 36-TQFN (6x5) |
|
|
PI2EQX3201BLZFEXIC REDRIVER SATA2 2CH 36TQFN |
0 |
|
Таблицы данных |
ReDriver™ | 36-WFQFN Exposed Pad | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | SATA2 | CML | CML | 3Gbps | 2 | 2.0ns | Input Equalization, Output De-Emphasis | - | 1.5V, 1.8V | 90mA | -40°C ~ 85°C | - | - | Surface Mount | 36-TQFN (6x5) |
|
|
PI2EQX3201BZFEIC REDRIVER 2CH 36TQFN |
0 |
|
Таблицы данных |
ReDriver™ | 36-WFQFN Exposed Pad | Tray | Obsolete | Buffer, ReDriver | - | CML | CML | 3.2Gbps | 2 | 2.0ns | Input Equalization, Output De-Emphasis | - | 1.5V, 1.8V | - | 0°C ~ 70°C | - | - | Surface Mount | 36-TQFN (6x5) |
|
PI2EQX3202BNBEXIC REDRIVER 2CH 3.2GBPS 84LFBGA |
0 |
|
Таблицы данных |
ReDriver™ | 84-LFBGA | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | SATA | CML | CML | 3.2Gbps | 4 | 2.0ns | Input Equalization, Output De-Emphasis | - | 1.4V ~ 1.9V | - | 0°C ~ 70°C | - | - | Surface Mount | 84-LFBGA (9x9) |
|
PI2EQX3211BHEIC REDRIVER SATA 2CH 20SSOP |
0 |
|
Таблицы данных |
ReDriver™ | 20-SSOP (0.209", 5.30mm Width) | Tube | Obsolete | Buffer, ReDriver | SATA | CML | CML | 3.2Gbps | 2 | 2.0ns | Input Equalization, Output De-Emphasis | - | 1.5V, 1.8V | - | 0°C ~ 70°C | - | - | Surface Mount | 20-SSOP |
|
PI2EQX3232AZDEIC REDRIVER SAS/SATA 2CH 48TQFN |
0 |
|
Таблицы данных |
ReDriver™ | 48-VFQFN Exposed Pad | Tray | Obsolete | Buffer, ReDriver | SAS, SATA | CML | CML | 3.2Gbps | 2 | 2.0ns | Input Equalization, Output De-Emphasis | - | 1.8V | - | 0°C ~ 70°C | - | - | Surface Mount | 48-TQFN (7x7) |
|
PI2EQX5804CNJEXIC REDRIVER PCIE 4CH 100LBGA |
0 |
|
Таблицы данных |
ReDriver™ | 100-LBGA | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | PCIe | CML | CML | 5Gbps | 4 | 750ps | Input Equalization, Output De-Emphasis | 50 pF | 1.2V | 800mA | 0°C ~ 70°C | - | - | Surface Mount | 100-LBGA (11x11) |
|
|
PI2EQX5804DNJEIC REDRIVER PCIE 4CH 100LBGA |
0 |
|
Таблицы данных |
ReDriver™ | 100-LBGA | Tray | Obsolete | Buffer, ReDriver | PCIe | CML | CML | 5Gbps | 4 | 750ps | Input Equalization, Output De-Emphasis | 50 pF | 1.2V | 800mA | 0°C ~ 70°C | - | - | Surface Mount | 100-LBGA (11x11) |
|
|
PI2EQX5804DNJEXIC REDRIVER PCIE 4CH 100LBGA |
0 |
|
Таблицы данных |
ReDriver™ | 100-LBGA | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | PCIe | CML | CML | 5Gbps | 4 | 750ps | Input Equalization, Output De-Emphasis | 50 pF | 1.2V | 800mA | 0°C ~ 70°C | - | - | Surface Mount | 100-LBGA (11x11) |
|
PI2EQX5864CZFEXIC REDRIVER PCIE 4CH 56TQFN |
0 |
|
Таблицы данных |
PCI Express®(PCIe), ReDriver™ | 56-WFQFN Exposed Pad | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | PCIe | CML | CML | 5Gbps | 4 | 750ps | Input Equalization, Output De-Emphasis | 50 pF | 1.2V | 800mA | 0°C ~ 70°C | - | - | Surface Mount | 56-TQFN (11x5) |
|
PI2EQX6741SLZDEXIC REDRIVER SATA3 1CH 20TQFN |
0 |
|
Таблицы данных |
ReDriver™ | 20-WFQFN Exposed Pad | Tape & Reel (TR) | Obsolete | Buffer, ReDriver | SATA3 | CML | CML | 6Gbps | 1 | - | Input Equalization, Output Pre-Emphasis | - | 1.05V | - | - | - | - | Surface Mount | 20-TQFN (4x4) |
|
|
PI2EQX8804ANJEIC REDRIVER PCIE 4CH 100LBGA |
0 |
|
Таблицы данных |
PCI Express®(PCIe), ReDriver™ | 100-LBGA | Tray | Obsolete | Buffer, ReDriver | PCIe | CML | CML | 8Gbps | 4 | - | - | - | 1.5V | - | - | - | - | Surface Mount | 100-LBGA (11x11) |
|
|
PI2EQX8814ANJEIC REDRIVER 8CH LBGA |
0 |
|
- |
- | 100-LBGA | Tray | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | 100-LBGA (11x11) |
|
|
PI2EQX8814ANJEXIC REDRIVER 8CH LBGA |
0 |
|
- |
- | 100-LBGA | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | 100-LBGA (11x11) |
|
PI2EQX8864AZLEIC REDRIVER PCIE 4CH 72TQFN |
0 |
|
Таблицы данных |
PCI Express®(PCIe), ReDriver™ | 72-WFQFN Exposed Pad | Tray | Obsolete | Buffer, ReDriver | PCIe | - | - | 8Gbps | 4 | - | - | - | 1.5V | - | - | - | - | Surface Mount | 72-TQFN (11x5) |
