Фиксированные индукторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип | Материал - сердечник | Индуктивность | Допуск | Номинальный ток (Ампер) | Ток - Насыщение (Isat) | Экранирование | Сопротивление постоянному току (DCR) | Q @ Freq | Частота - саморезонансная | Номинальные значения | Рабочая температура | Частота индуктивности - Тест | Особенности | Тип крепления | Устройство поставщика Упаковка | Размер/измерение | Высота - в сидячем положении (макс.) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTCDRH74F-330M33UH SMD SHIELDED POWER INDUCTOR Central Technologies |
10 |
|
Таблицы данных |
CTCDRH74F | Nonstandard | Tape & Reel (TR) | Active | - | - | 33 µH | ±20% | - | 960mA | Shielded | 170mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.177" (4.50mm) |
|
|
CTCDRH74F-820M82UH SMD SHIELDED POWER INDUCTOR Central Technologies |
10 |
|
Таблицы данных |
CTCDRH74F | Nonstandard | Tape & Reel (TR) | Active | - | - | 82 µH | ±20% | - | 610mA | Shielded | 430mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.177" (4.50mm) |
|
|
CTCDRH74F-821M820UH SMD SHIELDED POWR INDUCTOR Central Technologies |
10 |
|
Таблицы данных |
CTCDRH74F | Nonstandard | Tape & Reel (TR) | Active | - | - | 820 µH | ±20% | - | 200mA | Shielded | 5.2Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.177" (4.50mm) |
|
CTMMP5026F-3R3MSMD Shielded Power Inductor Central Technologies |
10 |
|
Таблицы данных |
- | - | Bulk | Active | - | - | 3.3 µH | ±20% | 29 A | - | Shielded | 6.8mOhm | - | - | - | -55°C ~ 125°C | - | - | Surface Mount | - | 0.543" L x 0.508" W (13.80mm x 12.90mm) | 0.264" (6.70mm) |
|
|
CTMMP5026F-2R2MSMD Shielded Power Inductor Central Technologies |
10 |
|
Таблицы данных |
- | - | Bulk | Active | - | - | 2.2 µH | ±20% | 33 A | - | Shielded | 4.2mOhm | - | - | - | -55°C ~ 125°C | - | - | Surface Mount | - | 0.543" L x 0.508" W (13.80mm x 12.90mm) | 0.264" (6.70mm) |
|
|
CTMMP5026F-220MSMD Shielded Power Inductor Central Technologies |
10 |
|
Таблицы данных |
- | - | Bulk | Active | - | - | 22 µH | ±20% | 8 A | - | Shielded | 45mOhm | - | - | - | -55°C ~ 125°C | - | - | Surface Mount | - | 0.543" L x 0.508" W (13.80mm x 12.90mm) | 0.264" (6.70mm) |
|
|
CTMMP5026F-8R2MSMD Shielded Power Inductor Central Technologies |
10 |
|
Таблицы данных |
- | - | Bulk | Active | - | - | 8.2 µH | ±20% | 16 A | - | Shielded | 16.6mOhm | - | - | - | -55°C ~ 125°C | - | - | Surface Mount | - | 0.543" L x 0.508" W (13.80mm x 12.90mm) | 0.264" (6.70mm) |
|
|
CTMMP5026F-5R6MSMD Shielded Power Inductor Central Technologies |
10 |
|
Таблицы данных |
- | - | Bulk | Active | - | - | 5.6 µH | ±20% | 24 A | - | Shielded | 11.5mOhm | - | - | - | -55°C ~ 125°C | - | - | Surface Mount | - | 0.543" L x 0.508" W (13.80mm x 12.90mm) | 0.264" (6.70mm) |
|
|
CTMMP5026F-8R2NSMD Shielded Power Inductor Central Technologies |
10 |
|
Таблицы данных |
- | - | Bulk | Active | - | - | 8.2 µH | ±30% | 16 A | - | Shielded | 16.6mOhm | - | - | - | -55°C ~ 125°C | - | - | Surface Mount | - | 0.543" L x 0.508" W (13.80mm x 12.90mm) | 0.264" (6.70mm) |
|
|
CTCDRH74F-470M47UH SMD SHIELDED POWER INDUCTOR Central Technologies |
9 |
|
Таблицы данных |
CTCDRH74F | Nonstandard | Tape & Reel (TR) | Active | - | - | 47 µH | ±20% | - | 880mA | Shielded | 260mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.177" (4.50mm) |
