Биполярные транзисторные матрицы, предварительно смещенные
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип транзистора | Ток - Коллектор (Ic) (Макс.) | Напряжение - Коллектор-Эмиттер Пробой (Макс.) | Резистор - База (R1) | Резистор - Эмиттер База (R2) | Усиление постоянного тока (hFE) (Мин.) @ Ic, Vce | Насыщение Vce (Макс.) @ Ib, Ic | Ток - Коллектор Отсечка (Макс.) | Частота - Переход | Мощность - макс. | Марка | Квалификация | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RN2904,LFTRANS 2PNP PREBIAS 0.2W US6 |
0 |
|
- |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | 2 PNP - Pre-Biased (Dual) | 100mA | 50V | 47kOhms | 47kOhms | 80 @ 10mA, 5V | 300mV @ 250µA, 5mA | 500nA | 200MHz | 200mW | - | - | Surface Mount | US6 |
|
|
RN4901,LFTRANS NPN/PNP PREBIAS 0.2W US6 |
0 |
|
- |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | 1 NPN, 1 PNP - Pre-Biased (Dual) | 100mA | 50V | 4.7kOhms | 4.7kOhms | 30 @ 10mA, 5V | 300mV @ 250µA, 5mA | 500nA | 200MHz, 250MHz | 200mW | - | - | Surface Mount | US6 |
|
|
RN4902,LFTRANS NPN/PNP PREBIAS 0.2W US6 |
0 |
|
- |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | 1 NPN, 1 PNP - Pre-Biased (Dual) | 100mA | 50V | 10kOhms | 10kOhms | 50 @ 10mA, 5V | 300mV @ 250µA, 5mA | 500nA | 200MHz | 200mW | - | - | Surface Mount | US6 |
|
UMH1NTNTRANS 2NPN PREBIAS 0.15W UMT6 |
51 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | 2 NPN - Pre-Biased (Dual) | 100mA | 50V | 22kOhms | 22kOhms | 56 @ 5mA, 5V | 300mV @ 500µA, 10mA | 500nA | 250MHz | 150mW | - | - | Surface Mount | UMT6 |
|
XN0F26100LTRANS PREBIAS DUAL NPN MINI6 |
0 |
|
Таблицы данных |
- | SOT-23-6 | Tape & Reel (TR) | Obsolete | 2 NPN - Pre-Biased (Dual) | 600mA | 20V | 3.3kOhms | - | 100 @ 50mA, 5V | 80mV @ 2.5mA, 50mA | - | 200MHz | 300mW | - | - | Surface Mount | MINI6-G1 |
|
|
RN1906(T5L,F,T)TRANS 2NPN PREBIAS 0.2W US6 |
0 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | 2 NPN - Pre-Biased (Dual) | 100mA | 50V | 4.7kOhms | 47kOhms | 80 @ 10mA, 5V | 300mV @ 250µA, 5mA | 100nA (ICBO) | 250MHz | 200mW | - | - | Surface Mount | US6 |
|
PQMH2ZTRANS PREBIAS 2NPN DFN1010B-6 |
0 |
|
Таблицы данных |
- | 6-XFDFN Exposed Pad | Tape & Reel (TR) | Active | 2 NPN - Pre-Biased (Dual) | 100mA | 50V | 47kOhms | 47kOhms | 80 @ 5mA, 5V | 150mV @ 500µA, 10mA | 1µA | 230MHz | 230mW | Automotive | AEC-Q101 | Surface Mount | DFN1010B-6 |
|
NHUMD10FTRANS PREBIAS 1NPN 1PNP 6TSSOP |
0 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | 1 NPN, 1 PNP - Pre-Biased (Dual) | 100mA | 80V | 2.2kOhms | 47kOhms | 100 @ 10mA, 5V | 100mV @ 500µA, 10mA | 100nA | 170MHz, 150MHz | 350mW | Automotive | AEC-Q101 | Surface Mount | 6-TSSOP |
|
|
NHUMB2FTRANS PREBIAS 2PNP 80V 6TSSOP |
0 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | 2 PNP - Pre-Biased (Dual) | 100mA | 80V | 47kOhms | 47kOhms | 100 @ 10mA, 5V | 100mV @ 500µA, 10mA | 100nA | 150MHz | 350mW | Automotive | AEC-Q101 | Surface Mount | 6-TSSOP |
|
|
NHUMB9FTRANS PREBIAS 2PNP 80V 6TSSOP |
0 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | 2 PNP - Pre-Biased (Dual) | 100mA | 80V | 10kOhms | 47kOhms | 100 @ 10mA, 5V | 100mV @ 500µA, 10mA | 100nA | 150MHz | 350mW | Automotive | AEC-Q101 | Surface Mount | 6-TSSOP |
|
|
NHUMH10FTRANS PREBIAS 1NPN 1PNP 6TSSOP |
0 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | 1 NPN, 1 PNP - Pre-Biased (Dual) | 100mA | 80V | 2.2kOhms | 47kOhms | 100 @ 10mA, 5V | 100mV @ 500µA, 10mA | 100nA | 170MHz, 150MHz | 350mW | Automotive | AEC-Q101 | Surface Mount | 6-TSSOP |
|
NP043A200ATRANS PREBIAS NPN/PNP SSSMINI6 |
0 |
|
Таблицы данных |
- | SOT-963 | Tape & Reel (TR) | Obsolete | 1 NPN, 1 PNP - Pre-Biased (Dual) | 80mA | 50V | 22kOhms | 22kOhms | 60 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | 150MHz, 80MHz | 125mW | - | - | Surface Mount | SSSMini6-F1 |
|
|
NP0G3D100ATRANS PREBIAS NPN/PNP SSSMINI6 |
0 |
|
Таблицы данных |
- | SOT-963 | Tape & Reel (TR) | Obsolete | 1 NPN, 1 PNP - Pre-Biased (Dual) | 80mA | 50V | 4.7kOhms, 47kOhms | 4.7kOhms, 47kOhms | 20 @ 5mA, 10V / 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | 150MHz, 80MHz | 125mW | - | - | Surface Mount | SSSMini6-F1 |
|
|
NP0H3A300ATRANS PREBIAS NPN/PNP SSSMINI6 |
0 |
|
Таблицы данных |
- | SOT-963 | Tape & Reel (TR) | Obsolete | 1 NPN, 1 PNP - Pre-Biased (Dual) | 80mA | 50V | 47kOhms | 47kOhms | 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | 150MHz, 80MHz | 125mW | - | - | Surface Mount | SSSMini6-F1 |
|
|
NP0G3D200ATRANS PREBIAS NPN/PNP SSSMINI6 |
0 |
|
Таблицы данных |
- | SOT-963 | Tape & Reel (TR) | Obsolete | 1 NPN, 1 PNP - Pre-Biased (Dual) | 80mA | 50V | 4.7kOhms, 22kOhms | 4.7kOhms, 47kOhms | 20 @ 5mA, 10V / 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | 150MHz, 80MHz | 125mW | - | - | Surface Mount | SSSMini6-F1 |
|
|
NP043A300ATRANS PREBIAS NPN/PNP SSSMINI6 |
0 |
|
Таблицы данных |
- | SOT-963 | Tape & Reel (TR) | Obsolete | 1 NPN, 1 PNP - Pre-Biased (Dual) | 80mA | 50V | 47kOhms | 47kOhms | 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | 150MHz, 80MHz | 125mW | - | - | Surface Mount | SSSMini6-F1 |
|
|
NP062AN00ATRANS 2NPN PREBIAS SSSMINI6 |
0 |
|
Таблицы данных |
- | SOT-963 | Tape & Reel (TR) | Obsolete | 2 NPN - Pre-Biased (Dual) | 80mA | 50V | 4.7kOhms | 47kOhms | 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | 150MHz | 125mW | - | - | Surface Mount | SSSMini6-F1 |
|
XP0421500LTRANS PREBIAS DUAL NPN SMINI6 |
0 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | 2 NPN - Pre-Biased (Dual) | 100mA | 50V | 10kOhms | - | 160 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | 150MHz | 150mW | - | - | Surface Mount | SMINI6-G1 |
|
RN1911FETE85LFTRANS 2NPN PREBIAS 0.1W ES6 |
0 |
|
Таблицы данных |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | 2 NPN - Pre-Biased (Dual) | 100mA | 50V | 10kOhms | - | 120 @ 1mA, 5V | 300mV @ 250µA, 5mA | 100nA (ICBO) | 250MHz | 100mW | - | - | Surface Mount | ES6 |
|
RN1971TE85LFTRANS 2NPN PREBIAS 0.2W US6 |
0 |
|
- |
- | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Obsolete | 2 NPN - Pre-Biased (Dual) | 100mA | 50V | 10kOhms | - | 120 @ 1mA, 5V | 300mV @ 250µA, 5mA | 100nA (ICBO) | 250MHz | 200mW | - | - | Surface Mount | US6 |
