Биполярные транзисторные матрицы, предварительно смещенные
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Тип транзистора | Ток - Коллектор (Ic) (Макс.) | Напряжение - Коллектор-Эмиттер Пробой (Макс.) | Резистор - База (R1) | Резистор - Эмиттер База (R2) | Усиление постоянного тока (hFE) (Мин.) @ Ic, Vce | Насыщение Vce (Макс.) @ Ib, Ic | Ток - Коллектор Отсечка (Макс.) | Частота - Переход | Мощность - макс. | Марка | Квалификация | Тип крепления | Устройство поставщика Упаковка |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NSVBC123JDXV6T1GSS SOT563 SRF MT RST XSTR onsemi |
0 |
|
Таблицы данных |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | 2 NPN - Pre-Biased (Dual) | 100mA | 50V | 2.2kOhms | 47kOhms | 80 @ 5mA, 10V | 250mV @ 1mA, 10mA | 500nA | - | 357mW | Automotive | AEC-Q101 | Surface Mount | SOT-563 |
|
NSB1010XV5T5DUAL DIGITAL TRANSISTORS onsemi |
0 |
|
Таблицы данных |
- | SOT-553 | Bulk | Discontinued at Digi-Key | 1 NPN, 1 PNP - Pre-Biased | 100mA | 50V | 4.7kOhms, 10kOhms | 4.7kOhms, 10kOhms | 15 @ 5mA, 10V / 35 @ 5mA, 10V | 250mV @ 1mA, 10mA / 250mV @ 300µA, 10mA | 500nA | - | 357mW | - | - | Surface Mount | SOT-553 |
|
NSB4904DW1T2GCOMPLEMENTARY BIPOLAR DIGITAL TR onsemi |
0 |
|
Таблицы данных |
- | 6-TSSOP, SC-88, SOT-363 | Bulk | Discontinued at Digi-Key | 1 NPN, 1 PNP - Pre-Biased | 100mA | 50V | 47kOhms | 47kOhms | 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | - | 187mW | - | - | Surface Mount | SC-88/SC70-6/SOT-363 |
|
EMD4DXV6T5COMPLEMENTARY BIPOLAR DIGITAL TR onsemi |
0 |
|
Таблицы данных |
- | SOT-563, SOT-666 | Bulk | Discontinued at Digi-Key | 1 NPN, 1 PNP - Pre-Biased | 100mA | 50V | 47kOhms | 47kOhms | 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | - | 357mW | - | - | Surface Mount | SOT-563 |
|
|
NSTB1005DXV5T5COMPLEMENTARY BIPOLAR DIGITAL TR onsemi |
0 |
|
Таблицы данных |
- | SOT-553 | Bulk | Discontinued at Digi-Key | 1 NPN, 1 PNP - Pre-Biased | 100mA | 50V | 47kOhms | 47kOhms | 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 500nA | - | 357mW | - | - | Surface Mount | SOT-553 |
|
EMF23XV6T5GDUAL NPN/PNP COMPLEMENTARY TRANS onsemi |
0 |
|
Таблицы данных |
- | SOT-563, SOT-666 | Bulk | Discontinued at Digi-Key | 1 NPN - Pre-Biased, 1 PNP | 100mA | 50V, 60V | 10kOhms | 10kOhms | 35 @ 5mA, 10V / 120 @ 1mA, 6V | 250mV @ 300µA, 10mA / 500mV @ 5mA, 50mA | 500nA, 500pA (ICBO) | 140MHz | 357mW | - | - | Surface Mount | SOT-563 |
|
|
EMF23XV6T5DUAL NPN/PNP COMPLEMENTARY TRANS onsemi |
0 |
|
Таблицы данных |
- | SOT-563, SOT-666 | Bulk | Discontinued at Digi-Key | 1 NPN - Pre-Biased, 1 PNP | 100mA | 50V, 60V | 10kOhms | 10kOhms | 35 @ 5mA, 10V / 120 @ 1mA, 6V | 250mV @ 300µA, 10mA / 500mV @ 5mA, 50mA | 500nA, 500pA (ICBO) | 140MHz | 357mW | - | - | Surface Mount | SOT-563 |
|
|
EMF18XV6T1GCOMPLEMENTARY BIPOLAR DIGITAL TR onsemi |
0 |
|
Таблицы данных |
- | SOT-563, SOT-666 | Bulk | Discontinued at Digi-Key | 1 NPN - Pre-Biased, 1 PNP | 100mA | 50V | 47kOhms | 47kOhms | 80 @ 5mA, 10V / 120 @ 1mA, 6V | 250mV @ 300µA, 10mA / 500mV @ 5mA, 50mA | 500nA, 500pA (ICBO) | 140MHz | 357mW | - | - | Surface Mount | SOT-563 |
|
|
NSB1011XV6T5DUAL DIGITAL TRANSISTORS onsemi |
0 |
|
Таблицы данных |
- | SOT-563, SOT-666 | Bulk | Discontinued at Digi-Key | 2 NPN - Pre-Biased | 100mA | 50V | 10kOhms, 2.2kOhms | 10kOhms | 35 @ 5mA, 10V / 80 @ 5mA, 10V | 250mV @ 300µA, 10mA | 100nA | - | 357mW | - | - | Surface Mount | SOT-563 |
