Симметрирующие трансформаторы
| Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Корпус/корпус | Упаковка | Состояние продукта | Диапазон частот | Импеданс - несбалансированный/сбалансированный | Разность фаз | Вносимые потери (макс.) | Обратные потери (мин.) | Тип крепления |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LDB21942M05C-001MULTI-LAY HYBRID BALUNS 0805 |
0 |
|
Таблицы данных |
LDB21 | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | 925MHz ~ 960MHz | 50 / 50Ohm | - | 1.5dB | - | Surface Mount |
|
|
LDB21942M10C-001MULTI-LAY HYBRID BALUNS 0805 |
0 |
|
Таблицы данных |
LDB21 | - | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - |
|
4550BL14A0100001TIC |
0 |
|
- |
- | - | Tape & Reel (TR) | Active | 3.2GHz ~ 6GHz | 1:2 | - | - | - | - |
|
TTB12G51-900-2P-T20BALUN 174MHZ-860MHZ 50/50 4SMD |
0 |
|
Таблицы данных |
TTB | 4-SMD | Tape & Reel (TR) | Obsolete | 174MHz ~ 860MHz | 50 / 50Ohm | 180° ±15° | 0.7dB | - | Surface Mount |
|
|
1720BL15B0050002EIC |
0 |
|
- |
- | - | Tape & Reel (TR) | Active | 625MHz ~ 2.815GHz | 1:1 | - | 1.5dB | - | - |
|
RFBLN1608050AM8T62BALUN 2.4GHZ-2.5GHZ 50/50 6SMD |
0 |
|
Таблицы данных |
RFBLN | 6-SMD | Tape & Reel (TR) | Active | 2.4GHz ~ 2.5GHz | 50 / 50Ohm | 180° ±10° | 1.2dB | 10dB | Surface Mount |
|
BLNK2-542R+1:2 LTCC TRANSFORMER, 4900 - 595 |
0 |
|
Таблицы данных |
- | 4-SMD, No Lead | Tape & Reel (TR) | Active | 4.9GHz ~ 5.95GHz | 1:2 | 2.4° | 1.0dB | 9.5dB | Surface Mount |
|
|
10R1BL14A0100001TIC |
0 |
|
- |
- | - | Tape & Reel (TR) | Active | 9GHz ~ 11GHz | - | - | - | - | - |
|
TBL-1608-245-M2BALUN 2.4GHZ-2.5GHZ 50/100 0603 |
0 |
|
Таблицы данных |
- | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | 2.4GHz ~ 2.5GHz | 50 / 100Ohm | 180° ±10° | 1.0dB | - | Surface Mount |
|
BW21S5011A01TFBALUN 45-870MHZ 50/50 0805 |
0 |
|
Таблицы данных |
BW-S | 0805 (2012 Metric), 4 PC Pad | Tape & Reel (TR) | Active | 45MHz ~ 870MHz | 50 / 50Ohm | - | 1.2dB | - | Surface Mount |
|
|
BD2326L50200AHFBALUN 2.3GHZ-2.6GHZ 50/200 0603 |
0 |
|
Таблицы данных |
Xinger® | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | 2.3GHz ~ 2.6GHz | 50 / 200Ohm | 3° | 0.9dB | 18dB | Surface Mount |
|
BLGE4-542R+1:4 LTCC TRANSFORMER, 4900 - 587 |
0 |
|
Таблицы данных |
- | 0805 (2012 Metric), 6 PC Pad | Tape & Reel (TR) | Active | 4.9GHz ~ 5.875GHz | 1:4 | 4.3° | 1.9dB | 7.3dB | Surface Mount |
|
|
ATB2012-50011MBALUN 40MHZ-860MHZ 50/50 0805 |
0 |
|
Таблицы данных |
- | 0805 (2012 Metric) | Tape & Reel (TR) | Active | 40MHz ~ 860MHz | 50 / 50Ohm | - | 1.02dB | - | Surface Mount |
|
|
ATB2012-75011MBALUN 50MHZ-1.2GHZ 75/75 0805 |
0 |
|
Таблицы данных |
- | 0805 (2012 Metric) | Tape & Reel (TR) | Active | 50MHz ~ 1.2GHz | 75 / 75Ohm | - | 0.8dB | - | Surface Mount |
|
|
2450BM07A0004001TBALUN MATCHED EIA0402 |
0 |
|
- |
- | - | Tape & Reel (TR) | Active | - | - | - | - | - | - |
|
|
2450BM14A0023001TIC |
0 |
|
- |
- | - | Tape & Reel (TR) | Active | 2.4GHz ~ 2.5GHz | - | - | - | - | - |
|
|
2450BM15B0026001EIC |
0 |
|
- |
- | 0805 (2012 Metric), 6 PC Pad | Tape & Reel (TR) | Active | 2.4GHz ~ 2.5GHz | 50Ohm | 180° ±10 | 1.5dB | 9.5dB | Surface Mount |
|
|
2450BM15A0002002EIC |
0 |
|
- |
- | - | Tape & Reel (TR) | Active | 2.4GHz ~ 2.5GHz | - | - | 1.7dB | - | - |
|
|
2450FB15M0001001EBALUN 2.4GHZ-2.5GHZ 0805 |
0 |
|
Таблицы данных |
- | 0805 (2012 Metric), 8 PC Pad | Tape & Reel (TR) | Obsolete | 2.4GHz ~ 2.5GHz | 50 / -Ohm | 180° ±15° | 3.0dB | 9.5dB | Surface Mount |
|
|
2450BM15A0015001EP1IC |
0 |
|
Таблицы данных |
- | 0805 (2012 Metric), 6 PC Pad | Tape & Reel (TR) | Active | 2.4GHz ~ 2.5GHz | 50Ohm | 180° ±10° | 1.5dB | 9.5dB | Surface Mount |
