Фотографии | Производитель. Часть # | Доступность | Количество | Таблицы данных | Серия | Упаковка | Состояние продукта | Тип | Количество выходов | Напряжение - Вход | Напряжение - выход 1 | Напряжение - Выход 2 | Напряжение - Выход 3 | Напряжение - Выход 4 | Напряжение - Выход 5 | Напряжение - Выход 6 | Ток - Выход 1 | Ток - Выход 2 | Ток - Выход 3 | Ток - Выход 4 | Ток - Выход 5 | Ток - Выход 6 | Мощность (Вт) | Применение | Напряжение - Изоляция | Рабочая температура | Особенности | Тип крепления | Размер/измерение |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
1010288SRP-100-4004 Integrated Power Designs |
19 |
|
- |
SRP-100 (100W) | Box | Active | Chassis | 4 | 100 ~ 240 VAC | 5V | -5V | 15V | -15V | - | - | 12 A | 4 A | 2 A | 1 A | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.50" H (127.0mm x 83.8mm x 38.1mm) |
![]() |
1010287SRP-100-4003 Integrated Power Designs |
18 |
|
- |
SRP-100 (100W) | Box | Active | Chassis | 4 | 100 ~ 240 VAC | 5V | -5V | 12V | -12V | - | - | 12 A | 4 A | 2 A | 1 A | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.50" H (127.0mm x 83.8mm x 38.1mm) |
![]() |
1010285SRP-100-4001 Integrated Power Designs |
7 |
|
- |
SRP-100 (100W) | Box | Active | Chassis | 4 | 100 ~ 240 VAC | 5V | 24V | 12V | -12V | - | - | 12 A | 3 A | 2 A | 1 A | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.50" H (127.0mm x 83.8mm x 38.1mm) |
![]() |
1010846NXT-225-1005 Integrated Power Designs |
8 |
|
![]() Таблицы данных |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 15V | - | - | - | - | - | 15 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) |
![]() |
1010849NXT-225-1008 Integrated Power Designs |
2 |
|
![]() Таблицы данных |
NXT-225 (225W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 48V | - | - | - | - | - | 4.7 A | - | - | - | - | - | 225W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.50" H (127.0mm x 76.2mm x 38.0mm) |
![]() |
1010913NXT-175-1004,LS-RE Integrated Power Designs |
14 |
|
![]() Таблицы данных |
NXT-175 (175W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 12V | - | - | - | - | - | 14.6 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.25" H (127.0mm x 76.2mm x 31.7mm) |
![]() |
1010917NXT-175-1008,LS-RE Integrated Power Designs |
2 |
|
![]() Таблицы данных |
NXT-175 (175W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 48V | - | - | - | - | - | 3.6 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.25" H (127.0mm x 76.2mm x 31.7mm) |
![]() |
1010915NXT-175-1006,LS-RE Integrated Power Designs |
2 |
|
![]() Таблицы данных |
NXT-175 (175W) | Box | Active | Open Frame | 1 | 100 ~ 240 VAC | 24V | - | - | - | - | - | 7.3 A | - | - | - | - | - | 175W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.25" H (127.0mm x 76.2mm x 31.7mm) |
![]() |
1011435GRN-200-4002 Integrated Power Designs |
5 |
|
- |
GRN-200 (200W) | Box | Active | Open Frame | 4 | 85 ~ 264 VAC | 5V | 3.3V | 12V | -12V | - | - | 30 A | 8 A | 2 A | 2 A | - | - | 200W | ITE (Commercial), Medical | - | -20°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.18" H (127.0mm x 76.2mm x 30.0mm) |
![]() |
1010272SRW-100-4004 Integrated Power Designs |
20 |
|
![]() Таблицы данных |
SRW-100 (100W) | Box | Active | Chassis | 4 | 100 ~ 240 VAC | 5V | -5.2V | 12V | -12V | - | - | 10 A | 4 A | 2 A | 1 A | - | - | 100W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 5.00" L x 3.30" W x 1.50" H (127.0mm x 83.8mm x 38.1mm) |
